ESS CONTROL SA-23G/H

READERS

UHF READERS

AY-L23G/H

Extra Long-Range RF Reader Dual Channel Transmitter for AY-L23 Receiver

Specification SA-23G/H Specification AY-L23G/H
Input Voltage
Input Current: Standby (12 VDC) 3 V Battery (CR2450) Operating Voltage 7–24 VDC
Input Current: Max (16 VDC) < 1 uA Standby Input Current 26 mA
Tamper Output 10 mA Max. Input Current 65 mA
Max. Remote Control Read Range
ID Format Open collector, active Open, max Operating Temp. Range 50 m (165 ft)
Frequencies sink current 16 mA Operating Humidity Range -31°C to 63°C (-25°F to 145°F)
Outdoor Usage
Operating Temp. Range Programmed to Wiegand 26-Bit Dimensions (H x W x D) 0 to 95% (non-condensing)
Operating Humidity Range G: 433.92 MHz (ASK) Weight Weather-resistant, meets IP65
Dimensions (H x W x D) H: 868.35 MHz (ASK) 145 x 43 x 20 mm (5.7 x 1.7 x 0.9 in.)

-31°C to 63°C (-25°F to 145°F) 500 g (1.10 lb)
0 to 95% (non condensing)
58 x 41 x 13.4 mm
(2.28 x 1.61 x 0.53 in.)

AY-U900

Specification AY-U900

Operating Voltage Range 9 to 12 VDC (2 A)

Input Current: Standby (12 VDC) 0.2 A max

Input Current: Max Read: 1.2 A max
(16 VDC)

Max Proximity Card Read Range* Up to 12 m (39.4 ft)

Operating Temp. Range -20°C to 80°C
(-4°F to 176°F)

Operating Humidity Range 0 to 95%
(non-condensing)

Dimensions (H x W x D) 44.5 x 44.5 x 6.7 cm
(17.52 x 17.52 x 2.64 in.)

UHF Integrated Long-Range Reader Weight 2.32 kg (5.11 lb)
* Read range was tested with a Rosslare UHF card.
