ESS CONTROL
13.56 MHz MIFARE® CLASSIC – CSN & READ SECTOR
MIFARE® SMART CARD CONTACTLESS READER SERIES
AY-H25B AY-L25B AY-J25B AY-K25B
US Gang Box Sized Mullion MIFARE® Mini-Mullion MIFARE® Micro-Mullion MIFARE®
MIFARE® Contactless Smart Contactless Smart Card Contactless Smart Card Contactless Smart Card
Card Reader (CSN only) Reader (CSN only) Reader (CSN only) Reader (CSN only)
AY-M25B
AY-M26 Major Features
UK Gang Box Sized
MIFARE® Contactless UK Gang Box Sized • ISO-14443A, MIFARE at 13.56 MHz
Smart Card Reader MIFARE® Contactless
Smart Card Sector Reader • Programmable multi-format output: Wiegand
26-Bit with Site Code, Fixed 26-Bit, 32-Bit, 32-Bit
Reversed, 34-Bit, 40-Bit and Clock & Data using
MD-08B (AY-M26, using AS-B01 and CP-R25/6)
• Bi-colored LED and buzzer indicators
• Programmable input: LED control/buzzer control
• Epoxy-potted – meets IP65, waterproof
• Optical back tamper
Specification AY-K25B AY-H25B AY-L25B AY-J25B AY-M25B AY-M26
Operating Voltage Range 5–16 VDC 6.5-16 VDC
Standby Input Current 110 mA
Maximum Input Current 35 mA 165 mA
Tamper Output
55 mA Open collector, active low,
max sink current 30 mA
Open collector, active low,
max sink current 16 mA 70 mm (2.76 in.)
Max. Read Range* 60 mm (2.36 in.) 70 mm (2.76 in.) 45 mm (1.77 in.)
Operating Temp. Range 79.91 x 39.91x 12.8 mm -31°C to 63°C (-25°F to 145°F)
(3.15 x 1.57 x 0.50 in.)
Operating Humidity 0 to 95% (non-condensing)
Range
Outdoor Usage 109.9 x 74.9 x 15 Weather-resistant, meets IP65 89 x 89 x 15 mm
mm (4.33 x 2.95 x (3.50 x 3.50 x 0.59 in.)
Dimensions 144.9 x 42.9 x 20 mm 119.95 x 41.95 x 14 mm 88.9 x 88.9 x 15 mm
(H x W x D) 0.59 in.) (5.70 x 1.69 x 0.79 in.) (4.72 x 1.65 x 0.55 in.) (3.50 x 3.50 x 0.59 in.)
Weight 75.49 g (2.66 oz) 119.87 g (4.23 oz) 115.19 g (4.06 oz) 88.5 g (3.12 oz) 120.25 g (4.24 oz.) 116 g (4.09 oz)
* Tested with MIFARE Classic 1K NXP based card.
