ACCESS CONTROL

INDOOR PIN / PROXIMITY & PIN CONTROLLERS

AC-B31, AC-B32 AC-C31, AC-C32

Indoor PIN / Proximity & Indoor Mullion PIN / Proximity
PIN Standalone Controller & PIN Standalone Controller

AC-D31, AC-D32 AC-A41, AC-A42

Indoor PIN / Proximity & PIN Indoor PIN / Proximity & PIN
Standalone Controller Standalone Controller

Major Features
• 125 kHz, ASK type RFID Proximity, Wiegand 26-Bit (selected models)
• 3 user levels and three operation modes
• 2 tri-colored LED and buzzer indicators
• Bell, chime, siren, and strobe features available with BL-D40
• Case tamper
• Input for REX button
• 3.5 A lock relay

Specification AC-A41 AC-A42 AC-B31 AC-B32 AC-C31 AC-C32 AC-D31 AC-D32

Input Voltage 12–16 VDC/VAC
Max. Input Current (12 VDC)
Standby Input Current (12 VDC) 100 mA 60 mA 90 mA 60 mA 90 mA 60 mA 90 mA
Tamper Output 20 mA 40 mA
Max. Read Range* 20 mA 40 mA 20 mA 40 mA 20 mA 40 mA
N/A 90 mm
Open collector, active Open, max sink current 32 mA (3.5 in.)

N/A 90 mm N/A 90 mm N/A 70 mm
(3.5 in.)
(3.5 in.) (2.75 in.)

Operating Temperature Range -32°C to 63°C (-25°F to 145°F) 92 x 92 x 24 mm -31°C to 63°C (-25°F to 145°F ) 122 x 75 x 4 mm
Dimensions (H x W x D) 122 x 75 x 24 mm (3.62 x 3.62 x 0.94 in.) 130 x 42 x 18 mm (4.80 x 2.95 x 0.94 in.)

Weight (4.80 x 2.95 x 0.94 in.) 130 g (4.59 oz) (5.12 x 1.65 x 0.71 in.) 130 g (4.59 oz)
140 g (4.94 oz) 70 g (2.47 oz)

*Measured using a Rosslare clamshell proximity card or equivalent. Range also depends on the electrical environment and proximity to metal.
