ESS CONTROL

OUTDOOR BACKLIT PIN / PROXIMITY & PIN CONTROLLERS

AC-F43 AC-F44

Outdoor 3x4 Backlit PIN Outdoor 3x4 Backlit Proximity & PIN
Standalone Controller Standalone Controller

AC-G43 AC-G44

Outdoor Mullion 2x6 Backlit PIN Outdoor Mullion 2x6 Backlit Proximity &
Standalone Controller PIN Standalone Controller

Major Features
• 500 dual-code users
• 2 x 2 A relays
• 2 inputs with user programmable logic
• 2 tri-colored LED indicators
• 3 user levels and three modes of operation
• Optical case and back tamper protection
• Fully-potted, meets IP65
• Lockout feature on wrong entries (keypad/card tamper)
• Bell, chime, siren, and strobe features available with BL-D40

Specification AC-F43 AC-F44 AC-G43 AC-G44

Input Voltage VDC VDC 12–24 VDC

VAC 16–24 VAC

Max. Input Current (12 VDC) 125 mA 160 mA 125 mA 160 mA

Standby Input Current (12 VDC) 75 mA 95 mA 75 mA 95 mA

Tamper Output Open collector, active Open, max sink current 20 mA

Max. Read Range* N/A 75 mm (2.95 in.) N/A 80 mm (3.15 in.)

Operating Temperature Range -30°C to 65°C (-22°F to 150°F)

Operating Humidity Range 0 to 95% (non-condensing)

Outdoor Usage Weather-resistant, meets IP65

Size (H x W x D) 120.9 x 71.1 x 29.7 mm (4.72 x 2.80 x 1.17 in.) 135.4 x 44.2 x 28.5 mm (5.33 x 1.74 x 1.12 in.)

Weight 244 g (8.61 oz) 178 g (6.28 oz)

*Measured using a Rosslare clamshell proximity card or equivalent. Range also depends on the electrical environment and proximity to metal.

20 ROSSLARE | Product Catalog | ACCESS CONTROL
