3Megapixel Network Dome Camera SND-7084N/P
Key Features Video 1/2.8" 3.2M CMOS
Imaging Device 2,065(H) x 1,565(V)
• Max. 3M (2048 x 1536) resolution Total Pixels 2,065(H) x 1,553(V)
• 30fps@2,048 x 1,536 / 60fps@1,920 x 1,080 Effective Pixels Progressive
• 3 ~ 8.5mm (2.8x) motorized varifocal lens Scanning System Color : 0.1Lux (F1.2, 50IRE), 0.06Lux (F1.2, 30IRE)
• Simple focus (Motorized VF), P-Iris Min. Illumination B/W : 0.01Lux (F1.2, 50IRE), 0.006Lux (F1.2, 30IRE)
• Day & Night (ICR), Enhanced DIS, Defog S / N Ratio 50dB
• 3M real-time WDR (Max. 120dB) Video Output CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation
• Multi-crop streaming Lens DIP connector type
• PoE, micro SD/SDHC/SDXC memory slot Focal Length (Zoom Ratio)
• Bi-directional audio support, Built-in mic. Max. Aperture Ratio 3 ~ 8.5mm (2.8x) motorized varifocal
Angular Field of View F1.2
Min. Object Distance H : 100.12°(Wide) ~ 35.38°(Tele) / V : 73.76°(Wide) ~ 26.58°(Tele)
Focus Control 0.5m (1.64ft)
Lens Type / Mount Type Simple focus (Motorized V/F) / Manual, Remote control via network (Manual, Simple focus)
Pan / Tilt / Rotate DC auto iris, P-Iris / Board-in type
Pan / Tilt / Rotate Range
Operational 0° ~ 354° / 0° ~ 67° / 0° ~ 355°
Camera Title
Day & Night Off / On (Displayed up to 45 characters)
Backlight Compensation Auto (ICR) / Color / B/W / External / Schedule
Wide Dynamic Range Off / BLC / WDR
Contrast Enhancement 120dB
Digital Noise Reduction SSDR (Samsung Super Dynamic Range) (Off / On)
Digital Image Stabilization SSNRIII (2D+3D noise filter) (Off / On)
Defog Off / On
Motion Detection Off / Auto / Manual
Privacy Masking Off / On (4 zones with 4-sided polygon)
Gain Control Off / On (32 zones with 4-sided polygon)
White Balance Off / Low / Middle / High
Electronic Shutter Speed ATW / AWC / Manual / Indoor / Outdoor
Flip / Mirror Minimum / Maximum / Anti flicker (1 ~ 1/12,000sec)
Intelligent Video Analytics Off / On
Alarm I/O Tampering, Virtual line, Enter / Exit, (Dis)Appear,
Alarm Triggers Audio detection, Face detection with metadata
Input 1ea / Output 1ea
Alarm Events Motion detection, Tampering, Audio detection, Face detection, Network disconnection,
Network Video analytics, Alarm input
Ethernet File upload via FTP and E-mail, Notification via E-mail,
Video Compression Format Local storage (SD/SDHC/SDXC) or NAS recording at Event, External output
Resolution
RJ-45 (10/100BASE-T)
Max. Framerate H.264 (MPEG-4 part 10/AVC), MJPEG
2048 x 1536, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720,
Smart Codec 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
Video Quality Adjustment H.264 : Max. 30fps@2048 x 1536, Max 60fps@the other resolutions
Bitrate Control Method MJPEG : Max. 10fps@2048 x 1536
Streaming Capability
Audio In Max. 15fps@1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768
Audio Out Max. 30fps@800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
Audio Compression Format
Dimensions Unit : mm (inch) Audio Communication Manual mode (Area-based : 5ea), Face detection mode
IP H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control
10170.7.66((44..224"4)") Protocol H.264 : CBR or VBR, MJPEG : VBR
Multiple streaming (Up to 10 profiles)
Selectable (Mic in / Line in / Built-in mic),
Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm
Line out (3.5mm mono jack), Max output level : 1 Vrms
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz
G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP,
SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
HTTPS(SSL) login authentication, Digest login authentication
Security IP address filtering, User access log, 802.1x authentication
Streaming Method Unicast / Multicast
Max. User Access 15 users at unicast mode
micro SD/SDHC/SDXC
Edge Storage Motion images recorded in the SDXC/SDHC/SD memory card can be downloaded
ØØ9977..00(3(3.8.28")2") Ø1Ø31322..11 ((55.2."2)") NAS (Network Attached Storage)
Application Programming Interface ONVIF profile S, SUNAPI, SVNP 1.2
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese,
Webpage Language Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch,
Croatian, Hungarian, Greek, Norwegian, Finnish
Accessories (Optional) Web Viewer Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7
Supported Browser : Microsoft Internet Explorer (Ver. 10, 9, 8),
Mozilla Firefox (Ver. 19, 18, 17, 16, 15, 14, 13, 12, 11, 10, 9),
Google Chrome (Ver. 25, 24, 23, 22, 21, 20, 19, 18, 17,16, 15),
Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only
SBP-300B SBP-300PM Central Management Software SmartViewer, SSM
Environmental
SHD-3000F1 SBP-301HM2 SBP-300LM SBP-300CM SBP-300WM1 SBP-300WM SBP-300KM Operating Temperature / Humidity -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH
* Data recorded on an SD memory card may be lost or damaged by data access during power-off, Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
mechanical shock, memory card detachment, or other operations. Data loss or damage can also occur Electrical
when a memory card reaches end of life, which varies according to operational conditions. Input Voltage / Current 12V DC, PoE (IEEE802.3af class 3)
No guarantee is given against damage (including passive damage). Power Consumption Max. 9.6W (12V DC), Max. 11.6W (PoE)
Mechanical
Color / Material Ivory / Plastic
Dimensions (WxH) Ø132.1 x 107.6mm (Ø5.2" x 4.24")
Weight 605g (1.33 lb)
* The latest product information / specification can be found at www.samsungsecurity.com
