7716/32NI-SP
Embedded Plug&Play NVR
Network Box Cameras VGA / HDMI Speaker
Network Dome Cameras
ACCESSIES INPUT OUTPUT Cell Phone
Network Speed Dome PC Client
Router
Door Contact
DS-7716/32NI-SP
control
Alarm USB Device USB Mouse Remote Control
Microphone
Key features DS-7716NI-SP DS-7732NI-SP
• Third-party network cameras supported Video/Audio input 16-ch 32-ch
• Up to 5MP resolution recording IP video input 1-ch, BNC (2.0 Vp-p, 1kΩ)
• HDMI and VGA output at up to 1920×1080P resolution Two-way audio input
• Plug & Play with 16 independent PoE network interfaces Network 80Mbps 160Mbps
• 4 SATA HDD interface up to 4TB each Incoming bandwidth 240Mbps 160Mbps
• HDD quota and group management Outgoing bandwidth 128
Remote Connection
Rear Panel of DS-7700NI-SP Video/Audio output 5MP / 3MP / 1080P / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
Recording resolution
1. Video out Main stream: 25 fps (P) / 30 fps (N)
2. CVBS audio out and VGA audio out Frame rate Sub-stream: 25 fps (P) / 30 fps (N)
3. Line in 1-ch, BNC (1.0 Vp-p, 75 Ω)
4. RS-232 interface CVBS output Resolution: 704 × 576 (PAL); 704 × 480 (NTSC)
5. VGA interface 1-ch, resolution:
6. HDMI interface HDMI output 1920 × 1080P /60Hz, 1920 × 1080P / 50Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz,
7. eSATA interface 1280 × 720 /60Hz, 1024 × 768 /60Hz
8. LAN interface VGA output 1-ch, resolution:
9. Termination switch 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
10. RS-485 interface, Controller port, Audio output
Decoding 2-ch, BNC (Linear, 600Ω)
Alarm in and Alarm out Live view / Playback
11. Ground resolution 5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF
12. AC 100V ~ 240V Capability 16-ch@720P, 8-ch@1080P
13. Power Hard disk
14. USB interface SATA 4 SATA interfaces for 2 HDDs + 1 DVD-R/W (default), or 4HDDs
15. Network interfaces with PoE function eSATA 1 eSATA interface
Capacity Up to 4TB capacity for each HDD
External interface
Network interface 1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interface
Serial interface RS-232; RS-485; Keyboard
USB interface 3 × USB 2.0
Alarm in/out 16/4
PoE
Interface 16 independent 100 Mbps PoE network interfaces
Max. Power 200W
Supported standard AT and AF
Others
Power supply 100 ~ 240VAC, 6.3A, 50 ~ 60Hz
Consumption
Working temperature ≤ 40 W ≤ 45 W
Working humidity
Chassis --10 ºC ~ +55 ºC (14ºF ~ 131ºF)
Dimensions(W × D × H)
Weight 10% ~ 90%
19-inch rack-mounted 1.5U chassis
445 × 390 ×70 mm
≤4 Kg /8.8 lb(without hard disk or DVD-R/W)
