7716/32NI-ST
Embedded NVR
Network Box Cameras VGA / HDMI Speaker PTZ DOME
Network Dome Cameras
ACCESSIES INPUT OUTPUT Cell Phone
Network Speed Dome PC Client
Router
Door Contact
DS-7716/32NI-ST
control NETWORK
Alarm USB Device USB Mouse Remote Control
Microphone
Key features DS-7716NI-ST DS-7732NI-ST
• Third-party network cameras supported Video/Audio input 16-ch 32-ch ANALOG
• Up to 5 Megapixels resolution recording IP video input 1-ch, BNC (2.0 Vp-p, 1kΩ)
• HDMI and VGA output at up to 1920×1080P resolution Two-way audio input
• HDD quota and group management Network 80Mbps 160Mbps
Incoming bandwidth 240Mbps 160Mbps
Rear Panel of DS-7700NI-ST Outgoing bandwidth 128
Remote Connection DVR
1. Video out Video/Audio output
2. CVBS Audio out and VGA audio out Recording resolution 5MP / 3MP / 1080P / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF NVR
3. Line in
4. RS-232 interface Frame rate Main stream: 25 fps (P) / 30 fps (N)
5. VGA interface Sub-stream: 25 fps (P) / 30 fps (N)
6. HDMI interface CVBS output 1-ch, BNC (1.0 Vp-p, 75 Ω)
7. eSATA interface Resolution: 704 × 576 (PAL); 704 × 480 (NTSC)
8. LAN interface HDMI output 1-ch, resolution:
9. Termination switch 1920 × 1080P /60Hz, 1920 × 1080P / 50Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz,
10. RS-485 interface, Controller port, VGA output 1280 × 720 /60Hz, 1024 × 768 /60Hz
1-ch, resolution:
Alarm in and Alarm out Audio output 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
11. Ground Decoding
12. AC 100V ~ 240V Live view / Playback 2-ch, BNC (Linear, 600Ω)
13. Power resolution
14. USB interface Capability 5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF ATM DVR
Hard disk 16-ch@720P, 8-ch@1080P
SATA
eSATA 4 SATA interfaces for 2 HDDs + 1 DVD-R/W (default), or 4HDDs ENCODER
Capacity 1 eSATA interface DECODER
External interface Up to 4TB capacity for each HDD
Network interface
Serial interface 1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interface CARD
USB interface RS-232; RS-485; Keyboard
Alarm in/out 3 × USB 2.0
General 16/4
Power supply
Consumption 100 ~ 240VAC, 6.3A, 50 ~ 60Hz
Working temperature
Working humidity ≤ 40 W ≤ 45 W
Chassis
Dimensions(W × D × H) --10 ºC ~ +55 ºC (14ºF ~ 131ºF)
Weight
10% ~ 90% NETWORK
STORAGE
19-inch rack-mounted 1.5U chassis
445 × 390 ×70 mm
≤ 4 Kg /8.82 lb ( without hard disk or DVD-R/W )
www.hikvision.com 177
