96128/256NI-E16(-E24)(/H)
Embedded NVR
Network Box Cameras VGA / HDMI Speaker PTZ DOME
Network Dome Cameras DS-9600NI-E16(-E24)(/H)
ACCESSIES INPUT OUTPUT Cell Phone
Network Speed Dome PC Client
Router
Door Contact
control NETWORK
Alarm USB Device USB Mouse Remote Control
Microphone
Key features DS-96128NI-E16 DS-96256NI-E16 DS-96128NI-E24 DS-96256NI-E24
DS-96128NI-E16/H DS-96256NI-E16/H DS-96128NI-E24/H DS-96256NI-E24/H
• Third-party network cameras supported
• Up to 8 Megapixels resolution recording Video/Audio input ANALOG
• Support up to 6-ch HDMI, 1-ch VGA at up to 1920×1080P
and 1 LCD touch screen simultaneous outputs IP video input 128-ch 256-ch 128-ch 256-ch
• Up to 128/256 IP cameras can be connected with
320M/640M incoming bandwidth Two-way audio input 1-ch, RCA (2.0 Vp-p, 1kΩ)
• Up to 24 SATA interfaces
• Support redundant power supply to improve the system Network
stability
• Supports HDD hot swap with RAID0,1,5,10 storage Incoming bandwidth 400Mbps 640Mbps 400Mbps 640Mbps
scheme configurable
Outgoing bandwidth 400Mbps 320Mbps 400Mbps 320Mbps
Rear Panel of DS-96256NI-E24(/H)
Remote Connection 256 DVR
1. AUDIO OUT
2. AUDIO IN Video/Audio output
3. 4 Fiber Optic Interfaces
4. 4 LAN Network Interfaces Recording resolution 8MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
5. VGA Interface
6. RS-232 Serial Interface LCD output (Optional) 7” LCD touch screen N/A
7. HDMI Interfaces HDMI output
8. USB 3.0 Interfaces 2-ch (/H models supports the HDMI outputs to be expanded to 6 channels), resolution: NVR
9. miniSAS Interface VGA output 1920 × 1080P /60Hz, 1920×1080P /50Hz, 1600 × 1200/60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz,
10. Termination Switch Audio output 1024 × 768 /60Hz
11. RS-485 Serial Interface, Keyboard Interface, 1-ch, resolution:
12. eSATA Interface 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
13. 100~240VAC Power InputPower switch
1-ch, RCA (2.0Vp-p, 1KΩ)
Decoding 8MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF ATM DVR
Live view / Playback 8-ch@1080P (/H models: 24-ch@1080P)
resolution
Capability
Hard disk
SATA 16 SATA interfaces for 16 HDDs 24 SATA interfaces for 24 HDDs
eSATA 1 eSATA interface
miniSAS (Optional) 1 miniSAS interface
Capacity Up to 4TB capacity for each HDD
Disk array ENCODER
DECODER
Array type RAID0, RAID1, RAID5, RAID10
External interface
Network interface 4 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces
Optic fiber interface 4 1000 Mbps optic fiber interfaces
Serial interface RS-232; RS-485 (reserved); Keyboard; Rear panel: 2 × USB 3.0 CARD
Working humidity Front panel: 2 × USB 2.0
Alarm in/out Rear panel: 2 × USB 3.0
16/8
Others ≤ 300 W ≤ 450 W
Power supply -10ºC ~ +55ºC (14ºF ~ 131ºF)
Consumption NETWORK
(without hard disk) STORAGE
Working temperature
Working humidity 10 % ~ 90 %
Chassis 19-inch rack-mounted 3U chassis 19-inch rack-mounted 4U chassis
Dimensions(W × D × H) 442 × 494 ×146 mm 447 × 528 ×172mm
Weight ≤ 15.86 Kg (31.79 lb)(without hard disk)
