-1670D SRN-1670D
16CH Network Video Recorder Display NETWORK
Camera
Key Features Inputs Up to 16CH
• Up to 16CH, 3MP supported
• H.264, MJPEG, MPEG-4 multiple codec N/W Resolution VGA (640 x 480) / SVGA (800 x 600) / 4CIF (704 x 480) /
• 64Mbps network camera recording Camera 1.3M (1280 x 1024) / 2M (1920 x 1080) / 3M (2048 x 1536)
• Max. 5 HDDs
• HDMI/VGA local monitor Protocols Samsung
• e-SATA storage supported
• DVD-RW Live Multi Screen Display 1 / 4 / 6 / 8 / 9 / 13 / 16, Sequence
Dimensions
Performance
444040.0.0 ((1177.3.23")2")
Operating System Embedded Linux NVR
440.0 (17.32")
Compression H.264, MPEG-4, MJPEG
Recording Bit Rate 64Mbps
Recording Resolution 4CIF (704 x 480) / SVGA (800 x 600) / 1.3M (1280 x 1024) /
Mode 2M (1920 x 1080) / 3M (2048 x 1536)
Nomal, Manual, Schedule (Continuous / Event), Event (Pre / Post)
Overwrite Modes Selectable (Stop / Continuous) NETWORK
PERIPHERAL
Pre-alarm Up to 15sec (5,10,15sec) *4CIF standard resolution
Post-alarm Up to 6hour (5, 10, 20, 30sec,1, 3, 5, 10, 20min, 1, 2, 3, 4, 5, 6hour)
Playback Speed 120fps (Up to 4CH)
Search & Resolution 4CIF (704 x 480) / 1.3M (1280 x 1024) / 2M (1920 x 1080) / 3M (2048 x 1536)
Playback Search Mode Date/time, Event, Back up (*All search included preview function)
Playback Function Fast forward / backward, Slow forward / backward, Move one step up / down
Ethernet RJ-45, Gigabit Ethernet x 2 Analogue
Camera
Transmission Speed Up to 48Mbps,
Unlimited (48M) / 2 / 1.5 / 1Mbps / 800 / 600 / 500 / 400 / 300 / 200 / 100 / 50kbps
Network Bandwidth Control Automatic
Max. Remote Users Search 3 / Live unicast 10 / Live multicast 20
Protocol Support TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP, DDNS, RTP, RTSP
Monitoring SmartViewer, Webviewer
Internal HDD Up to 5 SATA HDDs
External (e-SATA Interface) Up to 2 expansion bay (*Model : SVS-5R) DVR
Storage DVD Writer (Back up) Yes
USB (Back up) 3 USB ports
File Format (Back up) BU (NVR player), EXE (Include player)
Security Password Protection 1Admin, 10 Group, 20 User per 1 group,
User can be assigned authority for function
Data Authentication Watermark
Interface LENS
Monitors VGA Analogue RGB 1024 x 768 / 1280 x 1024(60Hz) resolution
HDMI 720p/1080p(60Hz) resolution
Unit : mm (inch)
Input N/A (Network audio support, up to 16CH)
7.9 (0.73.")79.9( (00..33")") Audio Output RCA x 1 7.9(3.11)7.9(3.11)
Compression G.711, G.723.1, G.726
Input Terminal 16 inputs (NO/NC) PERIPHERAL
Alarm Output Terminal 4 relay outputs (NO/NC)
Remote Notification Notification via e-mail
Ethernet 2 RJ-45 10/100/1000 Base-T
430.403(10.64.30903(.")01(61.6.9933")") Connections USB USB 2.0, 3 ports426.8(1648.206.3)8(168.03)
eSATA 2 ports 437.7(1742.337.2)7(172.32)
Application Support Mouse, Remote controller
Dome Supported Samsung network products (Network PTZ) MONITOR
Protocols PTZ Cameras
General
Electrical Input Voltage / Current 100 ~ 240V AC ±10%, 50/60Hz, 4 ~ 1.5A
Power Consum4p40t(i1o7n3.23) Max. 56W (With 1x HDD)
Environmental Operating Tem4p4e0(r1a7t3u.2r3e) +0°C ~ +40°C (+32°F ~ +104°F)
Operating Humidity 20% ~ 85% RH
CONTROLLER
Dimensions (WxHxD) 440.0 x 88.0 x 430.0mm (17.32" x 3.46" x 16.93")7.5(2.95)7.5(828.(9354).65)88(34.65)
95.5(37.69)5.5(37.6)
7.57.(50(.0.33""))7.58(880..803."()03.(4863"8.).04 (63."4)6") Mechanical Weight (1x Hard Disks) Approx. 7.1Kg (15.65 lb)
Rack Mount Kit 2ea
Language Korean, Japanese, Chinese, English, French, German, Spanish, Italian, Russian,
Polish, Czech, Turkish, Netherlands, Portuguese, Swedish, Danish, Thai,
Romanian, Serbian, Croatian, Hungarian, Greek (22 Language)
* The latest product information / specification can be found at www.samsungsecurity.com Access Control
System
