3Megapixel Network Camera SNB-7004N/P
Video 1/2.8" 3.2M CMOS
Imaging Device 2,065(H) x 1,565(V)
Total Pixels 2,065(H) x 1,553(V)
Effective Pixels Progressive
Scanning System
Min. Illumination Color : 0.1Lux (F1.2, 50IRE), 0.06Lux (F1.2, 30IRE)
B/W : 0.01Lux (F1.2, 50IRE), 0.006Lux (F1.2, 30IRE)
S / N Ratio
* Lens not included Video Output 50dB
Lens CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation
Key Features Focus Control DIP connector type
• Max. 3M (2048 x 1536) resolution Lens Type
• 30fps@2,048 x1,536 / 60fps@1,920 x 1,080 Mount Type Simple focus (Motorized V/F) / Manual, Remote control via network (Manual, Simple focus, Day & Night)
• Simple focus, P-Iris Operational Manual / DC auto iris, P-Iris
Camera Title C / CS
Day & Night
Backlight Compensation Off / On (Displayed up to 45 characters)
Wide Dynamic Range Auto (ICR) / Color / B/W / External / Schedule
Contrast Enhancement Off / BLC / WDR
Digital Noise Reduction 120dB
Digital Image Stabilization SSDR (Samsung Super Dynamic Range) (Off / On)
Defog SSNRIII (2D+3D noise filter) (Off / On)
Motion Detection Off / On
Privacy Masking Off / Auto / Manual
Gain Control Off / On (4 zones with 4-sided polygon)
White Balance Off / On (32 zones with 4-sided polygon)
Electronic Shutter Speed Off / Low / Middle / High
Flip / Mirror ATW / AWC / Manual / Indoor / Outdoor
Intelligent Video Analytics Minimum / Maximum / Anti flicker (1 ~ 1/12,000sec)
Alarm I/O Off / On
Remote Control Interface Tampering, Virtual line, Enter / Exit, (Dis)Appear,
RS-485 Protocol Audio detection, Face detection with metadata
Alarm Triggers Input 1ea / Output 1ea
RS-485
Samsung-T/E, Pelco-P/D, Sungjin, Panasonic, Honeywell, AD, Vicon, GE, Bosch
Motion detection, Tampering, Audio detection, Face detection,
Network disconnection, Video analytics, Alarm input
• Day & Night (ICR), Enhanced DIS, Defog Alarm Events File upload via FTP and E-mail, Notification via E-mail,
• 3M real-time WDR (Max. 120dB) Network Local storage (SD/SDHC/SDXC) or NAS recording at Event, External output
• micro SD/SDHC/SDXC memory slot Ethernet RJ-45 (10/100BASE-T)
Video Compression Format H.264 (MPEG-4 part 10/AVC), MJPEG
• Bi-directional audio support, Built-in mic. Resolution 2048 x 1536, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720,
1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
Dimensions Unit : mm (inch) Max. Framerate H.264 : Max. 30fps@2048 x 1536, Max 60fps@the other resolutions
MJPEG : M ax. 10fps@2048 x 1536
Max. 15fps@1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768
Max. 30fps@800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
Smart Codec Manual mode (Area-based : 5ea), Face detection mode
Video Quality Adjustment H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability Multiple streaming (Up to 10 profiles)
Audio In Selectable (Mic in / Line in / Built-in mic),
Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm
Audio Out
Line out (3.5mm mono jack), Max output level : 1 Vrms
Audio Compression Format G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz
Audio Communication G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
IP Bi-directional audio
IPv4, IPv6
Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP,
SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
6666..66 ((22..6622")")
Security HTTPS(SSL) login authentication, Digest login authentication
Streaming Method IP address filtering, User access log, 802.1x authentication
Max. User Access Unicast / Multicast
15 users at unicast mode
Edge Storage micro SD/SDHC/SDXC
Motion images recorded in the SDXC/SDHC/SD memory card can be downloaded
7733..11 ((22..8888"")) 114477.8.8(5(5.8.82"2)") NAS (Network Attached Storage)
Application Programming Interface ONVIF profile S, SUNAPI, SVNP 1.2
Available Lenses / Accessories (Optional) Webpage Language English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese,
Web Viewer Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch,
Croatian, Hungarian, Greek, Norwegian, Finnish
Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7
Supported Browser : Microsoft Internet Explorer (Ver. 10, 9, 8),
Mozilla Firefox (Ver. 19, 18, 17, 16, 15, 14, 13, 12, 11, 10, 9),
Google Chrome (Ver. 25, 24, 23, 22, 21, 20, 19, 18, 17,16, 15),
Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only
SLA-M2890DN/ SLA-M 3180DN/ SHB-4300H/4300H1/4300H2 SHB-4200/4200H Central Management Software SmartViewer, SSM
Environmental
M2890PN M3180PN Operating Temperature / Humidity -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH
use with or Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Electrical
Input Voltage / Current 24V AC, 12V DC, PoE (IEEE802.3af class3)
Power Consumption Max. 11.1W (12V DC), Max. 12.6W (PoE), Max. 13.1W (24V AC, 50 ~ 60Hz)
STB-400 STH-500 STH-200 STB-4150V Mechanical
* Data recorded on an SD memory card may be lost or damaged by data access during power-off, Color / Material Black, Ivory / Aluminium, Plastic
mechanical shock, memory card detachment, or other operations. Data loss or damage can also occur Dimensions (WxHxD) 73.1 x 66.6 x 147.8mm (2.88" x 2.62" x 5.82")
when a memory card reaches end of life, which varies according to operational conditions. Weight 430g (0.95 lb)
No guarantee is given against damage (including passive damage).
* The latest product information / specification can be found at www.samsungsecurity.com
FIRST EDITION 07-2014 22
