ACCESS CONTROL
Specification AYC-W6500 AY-B1663 AY-B3663 AY-B4663 AY-B1660 AY-B2660
6–16 VDC
Operating Voltage 10–16 VDC (Reader 5–16 VDC
Range mode, from controller)
Standby Input Current 140 mA 85 mA 60 mA
Maximum Input Current 330 mA
Tamper Output Open Collector Output 513 mA 135 mA
Inputs Dry contact, Normally
Open 0 to 5 V Open collector, active low, max sink current 32 mA
Indicators N/A
Output Format Wiegand 26-Bit Programmable LED/buzzer control input, N.O., Dry Contact
or Clock & Data
Compatible Cards ISO 125 kHz Three blue LED indicators Two tri-colors LED
Max. Proximity Read 7.5 cm (3 in.)
Range Wiegand 26-Bit, Wiegand 32-Bit, Wiegand 34-Bit, Wiegand 40-Bit and Clock & Data
Operating Temp. Range -5°C to 60°C
(23°F to 140°F) MIFARE compatible ISO-14443A MIFARE ISO14443A-3 standard
Operating Humidity 10% to 90% RH 40 mm (1.57 in.)
Range (non-condensing)
Dimensions: (H x W x D) 131 x 125 x 35 mm -25°C to 60°C (-13°F to 140°F)
(5.16 x 4.92 x 1.38 in.)
Weight 270 g (9.52 oz) 5% to 90% (non-condensing) 30% to 85% (non-condensing)
70.1 x 54.1 x 39.1 mm 84.1 x 54.1 x 20.9 mm 85.4 x 50.6 x 27 mm 100 x 54 x 42 mm 102 x 54 x 32 mm
(2.76 x 2.13 x 1.54 in.) (3.31 x 2.13 x 0.82 in.) (3.36 x 1.99 x 1.06 in.) (3.94 x 2.13 x 1.65 in.) (4.02 x 2.13 x 1.26 in.)
81.5 g (2.88 oz) 106 g (3.74 oz) 94.5 g (3.33 oz) 79 g (2.79 oz) 156 g (5.50 oz)
READER MODULES MD-12W
MD-12C
OEM Proximity Reader Module
• 125 kHz ASK, EM RFID Proximity Reader Module
• Read range of 5 cm (2 in.)
• Input voltage: 5 VDC
• Dimensions: Diameter – 23 mm (0.9 in.), Height – 9 mm (0.35 in.)
• Available in Wiegand 26-Bit (MD-12W) and Rosslare format Clock & Data (MD-12C)
• Operating temperature range: -31°C to 63°C (-25°F to 145°F)
ROSSLARE | Product Catalog | ACCESS CONTROL 37
