PIN ONLY READERS
AYC-F54
Convertible 3x4 Backlit PIN Convertible 2x6 Backlit PIN
Reader/Controller Reader/Controller
AYC-E55 AYC-Q54B
Convertible 2x6 Ultra-Slim Convertible Anti-Vandal
PIN Reader/Controller Backlit 3x4 PIN Reader/
Controller
Specification AYC-F54 AYC-G54 AYC-E55 AYC-Q54B
Operating Voltage Range 5–16 VDC (in Reader mode, from controller)
Input Current: Standby (12 VDC)
Input Current: Max (16 VDC) 75 mA 15 mA 65 mA
Tamper Output
Max Proximity Card Read Range* 110 mA 40 mA 110 mA
Operating Temperature Range
Operating Humidity Range Open collector, active low, max sink current 32 mA Open collector, active low, max sink current 30mA
Outdoor Usage
Dimensions (H x W x D) N/A N/A N/A N/A
-35°C to 66°C (-31°F to 151°F) -30°C to 65°C (-22°F to 150°F ) -35°C to 66°C (-31°F to 151°F)
0 to 95% (non-condensing)
Waterproof, meets IP65 Waterproof, meets IP68 Waterproof, meets IP65
120 x 76 x 21 mm 137 x 44 x 21 mm 155 x 44 x 6.5 mm 120 x 76 x 21 mm
(4.72 x 2.99 x 0.83 in.) (5.39 x 1.73 x 0.83 in.) (6.10 x 1.73 x 0.26 in.) (4.72 x 2.99 x 0.83 in.)
Weight 215 g (7.58 oz) 160 g (5.64 oz) 120 g (4.23 oz) 480 g (16.93 oz)
*Measured using a Rosslare clamshell proximity card or equivalent. Range also depends on the electrical environment and proximity to metal.
