GENERAL PURPOSE INDUSTRIAL SWITCHES PX-23 / PX-34

PX-13

Piezoelectric buttons designed and Piezoelectric buttons with LED indicator, Piezoelectric buttons with light ring
developed using advanced technology designed and developed using advanced indication, designed and developed
• External power source not required technology using advanced technology
• Easy to install
• Easy to install
Electrical Specification • Wide range of voltage input to turn on the LED
Input Voltage Range • 2-LED control inputs
Input Current • External power source not required (PX-23)
Contact Resistance
Impulse Time N.O. PX-13 PX-23 PX-34
Finger Pressure on Button 12 VDC/AC
Button Life 5–12 VDC/AC
≤1 A

<100 Ohm
<50 ms

0.5 kg for 5 N
over 50 million cycles

Environmental Specification PX-13 PX-23 PX-34

Operating Environment Indoor and Outdoor -40°C to 70°C (-40°F to 158°F)
Outdoor Usage -60°C to 80°C (-76°F to 176°F)
Operating Temperature Range Waterproof, meets IP68
Storage Temperature Range 10% to 99%
Operating Humidity Range -30°C to 70°C (-22°F to 158°F) -30°C to 60°C (-22°F to 140°F)

-40°C to 80°C (-40°F to 176°F) -30°C to 70°C (-22°F to 158°F)

10% to 90%

Physical Specification PX-13 PX-23 PX-34

Height 19.5 mm (0.77 in.)
Diameter 29.5 mm (1.16 in.)
Standard Thread
Standard Wires 22 mm (0.87 in.)
Pigtail Length 24 AWG wire (UL1569)
Weight
Housing Colors 280 mm (11.02 in.)
22 g (0.78 oz)

Black, Natural (mat), Gold, Green, Red, Blue, White
