2CC52C2S-IT3P

HD720P EXIR Turret Camera

1/3” ICR BLC Camera DS-2CC52C2S-IT3P
Image Sensor
CMOS Effective Pixels 1/3" Progressive Scan CMOS
Min. Illumination 1280(H)*720(V)
Scan Shutter Time 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR
1/100 s to 1/100,000 s
Key features Lens 3.6mm (2.8mm, 6mm, 8mm, 12mm, 16mm optional)
Angle of View: 78.8°(3.6mm), 103°(2.8mm), 51.2°(6mm), 37.6°(8mm), 24.6°(12mm), 18.8°(16mm)
• HD720p video output Lens Mount M12
• True Day/Night Angle Adjustment Pan: 0 - 360°, Tilt: 0 - 90°, Rotation: 0 - 360°
• Up to 40m IR Distance with EXIR technology Day & Night ICR
• IP66 Weatherproof Synchronization Internal synchronization
Video Frame Rate 720p@25fps/720p@30fps
Dimensions HD Video Output SMPTE292M (HD-SDI)
General
Working -10 °C - 60 °C (14 °F - 140 °F)
Temperature/Humidity Humidity 90% or less (non-condensing)
Power Supply 12V DC±10%
Power Consumption Max. 6W
Weather Proof Ratings IP66
IR Range 40 meters
Dimension Φ 114.6 × 89.1mm(Φ 4.5” × 3.5”)
Weight 250 g (0.55lb)

Unit: mm

Accessories

DS-1272ZJ-110 DS-1258ZJ
Indoor/outdoor wall mount Indoor wall mount

Available models

PAL: DS-2CC52C2S-IT3P
