-1652D SRD-1652D
16CH CIF Real-time DVR Display
Key Features Video Inputs 16 Composite video 0.5-1 Vpp
• 16CH CIF real-time DVR Resolution NTSC : 720 x 480 / PAL : 720 x 576
• Up to 480(NTSC) / 400(PAL)fps recording rate NTSC : 480fps / PAL : 400fps
• VGA / Composite video output Frame Rate NTSC : 720 x 480 / PAL : 720 x 576
• Max. 4 internal HDDs 1 / 4 / 6 / 8 / 9 / 13 / 16 / Sequence / PIP
• DVD-RW, Smart phone support (Android / iOS) Live Resolution
Linux
Dimensions Multi Screen Display H.264
44404.00.0 ((1177.3.23")2") Performance
440.0 (17.32") Operating System Embedded
Compression
Record Rate NTSC : Up to 120fps@704 x 480 / PAL : Up to 100fps@704 x 576
NTSC : Up to 240fps@704 x 240 / PAL : Up to 200fps@704 x 288
NTSC : Up to 480fps@352 x 240 / PAL : Up to 400fps@352 x 288
Recording Mode NTSC : Manual, Schedule (Continuous / Event), Event (Pre / Post),Time lapse (0.9 / 1.9 / 3.8 / 7.5 / 15 / 30fps)
PAL : Manual, Schedule (Continuous / Event), Event (Pre / Post),Time lapse (0.8 / 1.6 / 3.1 / 6.2 / 12.5 / 25fps)
Event Video loss, Motion (Level 1 ~ 10), Alarm
Overwrite Modes Selectable (Stop / Continuous)
Pre-alarm Up to 5sec
Post-alarm Up to 6hour (5,10, 20, 30sec, 1, 3, 5, 10, 20min, 1, 2, 3, 4, 5, 6hour)
Search Mode Date/Time, Event, Back up, POS (*All search mode include preview function)
Search & Playback Function Fast forward / backward (2x, 4x, 8x, 16x, 32x, 64x) *Backward play with i-frame only
Playback Slow forward / backward (1/2x, 1/4x, 1/8x)
Step forward / backward (2x, 4x, 8x, 16x, 32x, 64x) *Backward play with i-frame only
Transmission Speed CIF 120/100fps
Up to 8Mbps, Unlimited (8M) / 2 / 1.5 / 1Mbps / 800 / 600 / 500 / 400 / 300 / 200 / 100 / 50kbps
Bandwidth Selectable
H.264 (4CIF / 2CIF / CIF selectable)
Bandwidth Control Search 3 / Live unicast 10 / Live multicast 20
TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP, DDNS, RTP, RTSP, SNMP
Network (IPv4) Stream NET-i viewer, SmartViewer, Webviewer
Android, iOS
Max. Remote Users RTP, RTSP, HTTP, CGI
Live 1
Protocol Support Up to 4 SATA HDDs
Yes
Monitoring 3 USB ports
BU (DVR player), EXE (Include player), AVI
Platform 1 Admin, 10 Group, 10 User per 1 group
Watermark
Smart Phone Protocol Support
1 VGA (800 x 600, 1024 x 768, 1280 x 1024)
Max. Remote Users 1 BNC (1 Vpp, 75 ohm)
Analogue spot (1 BNC, 1 Vpp, 75 ohm), support multi screen and camera title
Internal HDD 4CH line in (Built-in 4CH, RCA) / 1CH line out (RCA)
ADPCM
Storage DVD Writer (Back up) 16KHz
USB (Back up)
File Format (Back up)
Security Password Protection
Data Authentication
Interface
Unit : mm (inch) VGA
Monitors Main Composite
Spot Composite
Inputs / Output
Audio Compression
Sampling Rate
44262.846.(2168.6.8(8(101"6)6..808")0") Alarm Inputs / Output 426.84 (216.6.88(01"6).80")Terminal 16 inputs (NO/NC) / Terminal 4 relay outputs (NO),
44525.142.(5121.7.1(8(101"7)7..808")0") Connections 452.14 (512.7.18(01"7).80")Rating : 30V DC / 1A, 125V AC / 0.5A
Remote Notification
Ethernet Notification via e-mail
Serial Interface 1 RJ-45 10/100/1000 Base-T
USB RS-485 (Half) for PTZ, System keyboard, RS-232 support for POS interface (VSI-pro)
Application Support USB 2.0, 3 ports
Mouse, Remote controller
RS-485 Protocol Samsung-T/E, Pelco-D/P, Panasonic, Phillips, AD,
DIAMOND, ERNA, KALATEL, VCL TP, VICON, ELMO
General Input Voltage / Current 100 ~ 240V AC ±10%, 50/60Hz, Auto ranging
Electrical P44o0w.0e(1r7.C32o")nsumption Max. 12W (With 1x HDD)
Environmental O44p0e.0r(a1t7i.n32g") Temperature +0°C ~ +40°C (+32°F ~ +104°F)
Operating Humidity 20% ~ 85% RH
Mechanical Dimensions (WxHxD) 440.0 x 88.0 x 426.8mm (17.32" x 3.46" x 16.80")
Weight (With hard disks) Approx. 7.5Kg (16.53 lb)
8 88.8.00 (8(38.340.6(4"3).64"6)") Rack Mount Kit 2ea88.0 (838.406("3).46")
Language English, French, German, Spanish, Italian, Russian, Polish, Czech, Turkish,
Netherlands, Portuguese, Swedish, Danish, Rumania, Serbia, Croatia,
Hungary, Greek, Finnish, Norwegian, Korean, Japanese, Chinese (Traditional),
Thai, Taiwanese (25 Language)
* Coaxial communication not supported
* The latest product information / specification can be found at www.samsungsecurity.com
REVISED 07-2014 180
