Addressable

AMA-100 Addressable Glassbreak Detector

• Based on the Acuity® hardwire • Can be tested using the glassbreak
• glassbreak detector • simulator (AFT-100)
Detects all types of breaking glass: plate, Built-in tamper switch

laminated, safety and tempered

Approval Listings: FCC/IC, UL/ULC

AMB-300 Addressable Passive Infrared Detector

• Patented MLSP (Multi-Level Signal •• Built-in tamper switch hardwire
• IPnrtoecrcehsasningge)able lenses: wall-to-wall lens Based on the Bravo® 3

(standard), curtain lens, pet-immune lens motion detector
and corridor lens

Approval Listings: FCC/IC, UL/ULC

AMB-500 Addressable Ceiling-Mount Passive

Infrared Detector

• Based on the Bravo® 5 hardwire • Coverage diameter based on
• motion detector mounting height
Built-in tamper switch

Approval Listings: FCC/IC, UL/ULC

AMB-600 Addressable Pet-Immune Passive

Infrared Detector

• Based on the Bravo® 6 hardwire • Provides pet immunity up to
• motion detector • 85 lb (39 kg)
Patented MLSP (Multi-Level Signal Built-in tamper switch

Processing)

Approval Listings: FCC/IC, UL/ULC

Addressable sensors & accessories 25
