Wireless

WS4926 Wireless Photoelectric Smoke Detector

•••••• Automatic drift compensation • Non-contact sensitivity reading with
Built-in 85dB horn •• • handheld test meter (FSD-100)
Local test button Long-life lithium batteries included
Low profile design UL/ULC listed for residential applications
High/Low sensitivity reporting Low battery indication
Easy-maintenance removable

smoke chamber

Approval Listings: FCC/IC, UL/ULC, CSFM

WT4901 2-Way Wireless Indoor Siren

•• Siren Output – 85dB door chimes, •••• Front and back tamper detection
Siren sounds for alarms, Nominal battery life – 1 year
Compatible with ALEXOR & IMPASSA
• entry/exit delay and troubles and Onboard test button
Transmits RF status, low battery

tamper condition

Approval Listings: FCC/IC, UL/ULC, SIA CP-01, CSFM

WT4911 2-Way Wireless Outdoor Siren

•••• Siren Output – 100dB and squawks •••••• Large print area for company logo
Siren sounds for alarms for visual indication Front and back tamper detection
Strobe light functionality WT5500 IP34 rating
Provides temperature to Nominal battery life – 2-3 years
Compatible with ALEXOR & IMPASSA
• wire-free keypad low battery and Remote test capability
Transmits RF status,

tamper condition

Approval Listings: FCC/IC, UL/ULC, SIA CP-01

WS4985 Wireless Flood Detector

The wireless flood detector is based on the WS4945 wireless door/window contact that is connected to a
water probe through a 6 foot-wire. The product is enrolled as a flood zone detector with the following DSC
control panels: ALEXOR, PowerSeries 9047, IMPASSA, PC1616, PC1832, PC1864, PC4020, and is fully
supervised.

••• Built-in reed switch input ••• Case and wall tamper
Normally closed external contact End-of-line resistor
1 lithium battery included 4 year battery life

Approval Listings: FCC/IC
