Page 18 - Q SERIES WISENET
P. 18
-6010R/6020R/6030R QNV-6010R/6020R/6030R
2Megapixel Vandal-Resistant Full HD VIDEO 1/2.9” 2.19M CMOS
Network IR Dome Camera Imaging Device 2,000(H) x 1,121(V)
Total Pixels 1,984(H) x 1,105(V)
Effective Pixels Progressive
Scanning System Color : 0.15Lux, B/W : 0Lux (IR LED on)
Min. Illumination
LENS 2.8mm fixed (QNV-6010R), 3.6mm fixed (QNV-6020R), 6mm fixed (QNV-6030R)
Focal Length (Zoom Ratio)
Max. Aperture Ratio F1.8
H : 110.0˚ / V : 61.0˚ / D : 125.0˚ (QNV-6010R)
Angular Field of View H : 86.48˚ / V : 46.22˚ / D : 102.44˚ (QNV-6020R)
Lens Type H : 52.54˚ / V : 28.86˚ / D : 61.14˚ (QNV-6030R)
Fixed
Mount Type Board type
PAN / TILT / ROTATE
Pan / Tilt / Rotate Range 0° ~ 350° / 0° ~ 67° / 0° ~ 355°
OPERATIONAL
IR Viewable Length 20m (65.62ft) : QNV-6010R, 25m (82.02ft) : QNV-6020R, 30m (98.43ft) : QNV-6030R
Off / On (Displayed up to 20 characters per line)
Camera Title - W/W : English / Numeric / Special characters
- China : English / Numeric / Special / Chinese characters
QNV-6010R QNV-6020R/6030R - Common : M ulti-line (Max. 5), Color (Grey / Green / Red / Blue / Black / White),
Transparency, Auto scale by resolution
Day & Night True Day & Night
Backlight Compensation Off / BLC
Wide Dynamic Range 120dB
Digital Noise Reduction SSNR (Off / On)
Motion Detection Off / On (4ea polygonal zones)
Privacy Masking Off / On (6ea rectangular zones)
Key Features Gain Control Off / Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
• Max. 2M (1920 x 1080) resolution LDC (Lens Distortion Correction) Off / On (5 levels with min / max)
• Built-in 2.8mm fixed lens (QNV-6010R) Electronic Shutter Speed Minimum / Maximum / Anti flicker
Flip / Mirror Flip / Mirror / Hallway view
3.6mm fixed lens (QNV-6020R) Intelligent Video Analytics Motion detection with metadata, Tampering, Defocus detection
6mm fixed lens (QNV-6030R) Alarm I/O Input 1 / Output 1
• Max. 30fps@all resolutions (H.265/H.264) Motion detection, Tampering detection, SD card error, NAS error,
• H.265, H.264, MJPEG codec supported, Multiple streaming Alarm Triggers Alarm input, Defocus detection
• Motion detection, Tampering, Defocus detection
• micro SD (128GB) memory slot, PoE / 12V DC Alarm Events File upload via FTP and E-mail, Local storage recording at event,
• IR viewable length 20m (QNV-6010R), 25m (QNV-6020R) Pixel Counter Notification via E-mail, External output
30m (QNV-6030R) NETWORK Support (Plug-in viewer only)
• Hallway view, WiseStream support, IP66, IK10
• LDC support (Lens Distortion Correction) Ethernet RJ-45 (10/100BASE-T)
Video Compression Format H.265, H.264, MJPEG
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768,
Resolution 800 x 600, 720 x 576, 720 x 480, 640 x 480, 320 x 240
Max. Framerate H.265/H.264 : Max. 30fps at all resolutions, MJPEG : Max. 15fps
Smart Codec WiseStream
Video Quality Adjustment H.265/H.264 : Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method H.265/H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability Multiple streaming (Up to 3 profiles)
Audio I/O Line in
G.711 u-law / G.726 selectable
Dimensions Unit : mm (inch) Audio Compression Format G.726 (ADPCM) 8KHz, G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
Audio Communication Uni-directional audio
IP IPv4, IPv6
Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE,
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
HTTPS(SSL) login authentication, Digest login authentication
Security IP address filtering, User access log, 802.1x authentication
Streaming Method Unicast / Multicast
Max. User Access 6 users at unicast mode
micro SD/SDHC/SDXC Max. 128G, NAS
5511..22 ((22..002"2)") Storage - Motion images recorded in the SD memory card can be downloaded
9911..77 ((33..661"1)") - Manual recording at local PC
Application Programming Interface ONVIF Profile S/G, SUNAPI (HTTP API)
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese,
Webpage Language Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch,
Croatian, Hungarian, Greek, Norwegian, Finnish
Supported OS : Windows 7, 8, 10, Mac OS X 10.8, 10.9, 10.10, 10.11
Non-plugin Webviewer
- Supported Browser : Google Chrome 47, MS Edge 20
Web Viewer - Support Codec : - Video : H.264, MJPEG (Max. 1M 15fps) - Audio : G.711
Plug-in Webviewer
Supported Browser : MS Explore 11, Mozilla Firefox 43, Apple Safari 9 * Mac OS X only
ØØ112200..33((44.7.74"4)") ØØ121200..33 ((44..7744")") Central Management Software SmartViewer
SBP-300NB SBP-300B ENVIRONMENTAL
Accessories (Optional) -30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH
Operating Temperature / Humidity * Start up should be done at above -20°C (-4°F)
Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Ingress Protection / Vandal
Resistance IP66 / IK10
ELECTRICAL PoE (IEEE802.3af, Class3) / 12V DC
Input Voltage / Current Max. 7W (PoE), Max. 5.8W (12V DC) : QNV-6010R
Power Consumption Max. 6.8W (PoE), Max. 5.7W (12V DC) : QNV-6020R/6030R
MECHANICAL
Color / Material Ivory / Metal
Dimensions (WxH) Ø120.3 x 91.7mm (Ø4.74” x 3.61”)
Weight 490g (1.08 lb)
SBP-122HM SBP-300LM SBP-300CM SBP-300WM1 SBP-300WM SBP-300PM SBP-300KM * The latest product information / specification can be found at hanwha-security.eu
