-443 SRD-443
4CH CIF Real-time Compact Design DVR Display
Key Features Video Inputs 4 Composite video 0.5-1 Vpp, 75 ohm
• 4CH CIF real-time DVR Resolution NTSC : 720 x 480 / PAL : 720 x 576
• Up to 120(NTSC) / 100(PAL)fps recording rate NTSC : 120fps / PAL : 100fps
• VGA / Composite video output Frame Rate NTSC : 720 x 480 / PAL : 720 x 576
• Max. 1 internal HDD 1 / 4 / Sequence / PIP
• Smart phone support (Android / iOS) Live Resolution
• Smart searching, Tampering detection Linux
Multi Screen Display H.264
Dimensions
Performance
331155..00((1122.4."4) ")
Operating System Embedded
315.0 (12.4")
Compression
Record Rate NTSC : Up to 30fps@704 x 480 / PAL : Up to 25fps@704 x 576
NTSC : Up to 60fps@704 x 240 / PAL : Up to 50fps@704 x 288
NTSC : Up to 120fps@352 x 240 / PAL : Up to 100fps@352 x 288
Recording Mode NTSC / PAL : Manual, Schedule (Continuous / Event), Event (Pre / Post)
Event Video loss, Motion (Level 1 ~ 10), Alarm
Search & Overwrite Modes Selectable (Stop / Continuous)
Playback Pre-alarm Up to 5sec
Post-alarm Up to 6 hour (5,10, 20, 30sec,1, 3, 5, 10, 20min, 1, 2, 3, 4, 5, 6hour)
Search Mode Date/Time, Event, Back up, POS, Motion (*All search included preview function)
Playback Function Fast forward / backward (2x, 4x, 8x, 16x, 32x, 64x) *Backward play with I-frame only
Slow forward / backward (1/2x, 1/4x, 1/8x)
Transmission Speed CIF 120/100fps
Up to 4Mbps, Unlimited (4M) / 2 / 1.5 / 1Mbps / 800 / 600 / 500 / 400 / 300 / 200 / 100 / 50kbps
Bandwidth Automatic
H.264 (CIF)
Bandwidth Control Search 2 / Live unicast 4 / Live multicast 20
TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP, DDNS, RTP, RTSP
Network (IPv4) Stream SmartViewer, Webviewer, SSM (CMS)
Android, iOS
Max. Remote Users RTP, RTSP, HTTP, CGI
Live 2, Search 1
Protocol Support Up to 1 SATA HDD
2 USB ports
Monitoring BU (DVR player), EXE (Include player), AVI
1 Admin, 10 Group, 10 User per 1 group
Platform Watermark
Smart Phone Protocol Support 1 VGA (1024 x 768) *Main composite or VGA selected in booting
1 BNC (1 Vpp, 75 ohm)
Max. Remote Users Analgo spot (1 BNC, 1 Vpp, 75 ohm)
4CH line in / 1CH line out
Internal HDD G.711
8KHz
Storage USB (Back up)
File Format (Back up)
Security Password Protection
Data Authentication
Interface
VGA
Unit : mm (inch) Monitors Main Composite
Spot Composite
Inputs / Output
Audio Compression
Sampling Rate
224.02(228.248.4.20"0)((88..8822")") Alarm Inputs / Output Terminal 4 inputs (NO/NC) / Terminal 1 relay outputs (NO),
235.02 (329.53.25.05"0() (9.9.2255"")) Connections Rating : 24V DC / 1A, 125V AC / 0.5A
Remote Notification
Ethernet Notification via e-mail
Serial Interface 1 RJ-45 10/100 Base-T
USB RS-485 (Half) for PTZ, System keyboard
Application Support USB 2.0, 2 ports
Mouse, Remote controller
Protocol Support Samsung-T/E, Pelco-D/P, Panasonic, Phillips, AD,
DIAMOND, ERNA, KALATEL, VCL TP, VICON, ELMO
General
Electrical Input Voltage / Current 12V DC adaptor, 2A,100 ~ 240V AC, 50/60Hz, Max. 24watt
Power Consumption Max. 19.6W (with 1x HDD)
5522..00 ((22..5020.5"50)"()2.05") Environmental Operating Temperature +0°C ~ +40°C (+32°F ~ +104°F)
5577..00 ((2.5272.4"40)"()2.24") Operating Humidity 20% ~ 85% RH
Mechanical Dimensions (WxHxD) 315.0 x 52.0 x 224.0mm (12.4" x 2.05" x 8.82")
Weight (With hard disks) Approx. 1.6Kg (3.53 lb)
Language English, French, German, Spanish, Italian, Russian, Polish, Czech, Turkish,
Netherlands, Portuguese, Swedish, Danish, Rumania, Serbia, Croatia,
Hungary, Greek, Finnish, Norwegian, Korean, Japanese, Chinese (Traditional),
Thai, Taiwanese (25 Language)
* Coaxial communication not supported
* The latest product information / specification can be found at www.samsungsecurity.com
REVISED 07-2014 194
