Producator |
HIKVISION |
|
Numar canale |
4ch |
|
Carcasa |
Plastic |
| VIDEO | |
|
Numar intrari video |
4 |
|
Compresie |
H.265/H.265+/H.264/H.264+ |
|
Compatibilitate |
HDTVI/HDCVI/AHD/CVBS |
| PERFORMANTA | |
|
Tip camere suportate |
Analogic/HDTVI/AHD/HDCVI/IP Hikvision |
|
Rezolutii inregistrare |
8MPlite/5MP/4MP/3MP/1080p/720p, 4MP pentru camerele IP |
|
Frame rate |
Cu 1080p lite inactiv: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps. Cu 1080p lite activ: 3 MP@15fps, 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps |
|
Mod de inregistrare |
Continuu, detectie miscare, alarma, alarma/detectie miscare, program |
|
Rezolutie de redare |
8MP lite inactiv: 8fps@8MP, 12fps@5MP, 15fps@4MP, 18fps@3MP ; 8MP lite activ 15fp@toate rezolutiile |
|
Rezolutie max. inregistrare |
8MP |
|
Acces mobil |
Android, iOS |
|
Aplicatii mobile |
Hik-Connect |
| OPERATIONAL | |
|
Protocol |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| STOCARE | |
|
Capacitate maxima / HDD |
6 TB |
|
Back up |
USB, LAN, WAN |
|
Porturi SATA |
1 |
| INTERFETE | |
|
VGA |
Da |
|
HDMI |
Da |
|
Intrari audio |
1 |
|
Iesiri audio |
1 |
|
Compresie audio |
G.711u |
|
Interfata retea |
1x RJ45 10/100 Ethernet |
|
USB |
2x USB 2.0 |
| CONDITII DE MEDIU | |
|
Temperatura / umiditate functionare |
-10°C ~ +55°C / 10% ~ 90% RH |
| SPECIFICATII ELECTRICE | |
|
Alimentare |
12VDC |
|
Consum |
15W |
| SPECIFICATII FIZICE | |
|
Dimensiuni |
200 × 200 × 45 mm |
|
Greutate |
1.16 kg |
