P. 152
2CE5582P(N)-IRP
600TVL DIS Indoor IR Turret Camera
DS-2CE5582P(N)-IRP
Camera
Image Sensor 1/3” DIS
Signal System PAL/NTSC
Effective Pixels 720 (H) × 480 (V)
1/3” 600 Min. Illumination 0.1 Lux @ (F1.2,AGC ON),0 Lux with IR
Shutter speed PAL: 1/25 s to 1/15,000 s
DIS NTSC: 1/30 s to 1/15,000 s
Lens 3.6 mm (2.8mm,6 mm optional)
ICR Lens Mount Angle of view: 68.4° (3.6 mm)
Angle Adjustment
M12
Pan: 0 - 360°; Tilt: 0 - 85°; Rotation: 0 - 360°
BLC Day & Night IR cut filter with auto switch
Horizontal Resolution 600 TVL
Key features Synchronization Internal synchronization
• 600 TVL Horizontal Resolution Video Output 1Vp-p composite output (75 Ω/BNC)
• True Day/Night S/N Ratio More than 52 dB
• 2.8/3.6/6mm Fixed Lens, 0.1 lux /F1.2 General
• 20m IR Distance Working Temperature/Humidity -40 °C - 60 °C (-40 °F - 140 °F)
• Wide Operating Temperature Range: Power Supply Humidity 90% or less (non-condensing)
Power Consumption 12 V DC
-40°C to 60°C(-40ºF to +140ºF) IR Range Max. 2 W
(Max. 5 W with IR cut filter on)
Dimensions 20 meters
Dimensions Φ 89.5 × 69.8 mm (3.52” × 2.75”)
Weight 200g (0.44 lb)
Unit: mm
Available models
PAL: DS-2CE5582P-IRP
NTSC: DS-2CE5582N-IRP
152 www.hikvision.com
