Kantech Access Control and Security Management System
EntraPass Special Edition
Single Workstation Security Management Software
Features:
• Increased security with easy to set-up
integration of access, video, intrusion
and telephone entry systems
• Embedded high-performance Sybase
SQL database engine
• Controls up to 128 readers with KT-100 and KT-300;
256 readers with KT-400
• Fast and user-friendly installation and operation
• Built-in email reporting capability
Single Workstation System Alarm Panel Integration
EntraPass Special Edition is a single workstation security Alarm panel integration can be accomplished with the use
software. It controls up to 128 card readers with KT-100/ of the EntraPass software in one of two ways. The first way
KT-300 and up to 256 card readers with KT-400 door is to connect the software directly to the DSC PowerSeries
controllers. The software also includes a number of stand- or MAXSYS alarm panels. Alternatively, the KT-400 can
alone utilities that allow operators to perform a variety of be connected to the DSC PowerSeries or MAXSYS or
tasks such as: verifying the system database, changing the Honeywell Dimension alarm panels. Either connection
system language (English, Spanish, French, Portuguese, method allows the alarm panels to receive intrusion
Dutch, German, Italian, Chinese and Turkish), migrating events, view the status of zones, and manage partitions
from older versions of EntraPass, viewing reports, etc. and user codes. In addition the system can be armed/
disarmed (single or multiple partitions) via reader (KT-400
Site Architecture only) or manual operation.
EntraPass Special Edition can manage up to 64 sites
consisting of KT-100, KT-200, KT-300 and KT-400
controllers (up to 64 controllers).
Video Integration
Real-time monitoring capability is a response to the
growing importance of video in access control systems.
Integration with American Dynamics HDVR, ADTVR and
Intellex Digital Video Management Systems through the
powerful American Dynamics (the intergration is not done
through intellex API) Application Programming Interface
(API) provides real-time video monitoring as well as video
playback. Video can be linked to access events (such as
“door forced open”) and recorded from one to
sixteen cameras from different American Dynamics HDVR,
ADTVR and Intellex units simultaneously. All cameras can
be called up directly from a floor plan simply by
double-clicking on the camera or dome icon.
01/14 8
EntraPass Special Edition
Single Workstation Security Management Software
Features:
• Increased security with easy to set-up
integration of access, video, intrusion
and telephone entry systems
• Embedded high-performance Sybase
SQL database engine
• Controls up to 128 readers with KT-100 and KT-300;
256 readers with KT-400
• Fast and user-friendly installation and operation
• Built-in email reporting capability
Single Workstation System Alarm Panel Integration
EntraPass Special Edition is a single workstation security Alarm panel integration can be accomplished with the use
software. It controls up to 128 card readers with KT-100/ of the EntraPass software in one of two ways. The first way
KT-300 and up to 256 card readers with KT-400 door is to connect the software directly to the DSC PowerSeries
controllers. The software also includes a number of stand- or MAXSYS alarm panels. Alternatively, the KT-400 can
alone utilities that allow operators to perform a variety of be connected to the DSC PowerSeries or MAXSYS or
tasks such as: verifying the system database, changing the Honeywell Dimension alarm panels. Either connection
system language (English, Spanish, French, Portuguese, method allows the alarm panels to receive intrusion
Dutch, German, Italian, Chinese and Turkish), migrating events, view the status of zones, and manage partitions
from older versions of EntraPass, viewing reports, etc. and user codes. In addition the system can be armed/
disarmed (single or multiple partitions) via reader (KT-400
Site Architecture only) or manual operation.
EntraPass Special Edition can manage up to 64 sites
consisting of KT-100, KT-200, KT-300 and KT-400
controllers (up to 64 controllers).
Video Integration
Real-time monitoring capability is a response to the
growing importance of video in access control systems.
Integration with American Dynamics HDVR, ADTVR and
Intellex Digital Video Management Systems through the
powerful American Dynamics (the intergration is not done
through intellex API) Application Programming Interface
(API) provides real-time video monitoring as well as video
playback. Video can be linked to access events (such as
“door forced open”) and recorded from one to
sixteen cameras from different American Dynamics HDVR,
ADTVR and Intellex units simultaneously. All cameras can
be called up directly from a floor plan simply by
double-clicking on the camera or dome icon.
01/14 8
