PowerSeries

PC1404 PowerSeries Control Panel

•• 4 on-board zones provides •••••••• NC/Single/Double EOL support
Supervised zone doubling Supports up to 4 keypads
1 partition support
• expansion to 8 zones provides expansion 128 event buffer
Keypad zone support Communications: on-board PSTN
4 phone numbers
• to 8 zones all current PowerSeries PK 2 and 4-wire smoke detector support
Support for PC-Link Support for DLS

• collection keypads (v1.2 +) to 14 using
2 on board PGM, expansion

PowerSeries Output modules

Approval Listings: FCC/IC, UL/ULC, SIA CP-01, CSFM

PC1616 PowerSeries Control Panel

•••• 6 on-board zones • Template programming
Expandable to 16 hardwired zones •••• with keypad zones
Expandable to 32 wireless zones 2 partitions
2 PGM outputs: expandable to 14 500-event buffer
48 user codes
•• (PC5204, PC5208) keypads CP-01 compliant
Connect up to 8 supervised keypads
Supports WT5500 wire free

with TR5164-433 transceiver

Approval Listings: FCC/IC, UL/ULC, SIA CP-01, CSFM

PC1832 PowerSeries Control Panel

• 8 on-board zones • Template programming
• Expandable to 32 hardwired zones • 4 partitions
• Expandable to 32 wireless zones • 500-event buffer
• 2 PGM outputs: expandable to 14 • 72 user codes
• CP-01 compliant
(PC5204, PC5208) • Supports WT5500 wire free keypads
• Connect up to 8 supervised keypads
with TR5164-433 transceiver
with keypad zones

Approval Listings: FCC/IC, UL/ULC, SIA CP-01, CSFM

PC1864 PowerSeries Control Panel

• 8 on-board zones • 8 partitions
• Expandable to 64 hardwired zones • 500-event buffer
• Expandable to 64 wireless zones • 95 user codes
• 4 PGM outputs: expandable to 14 • CP-01 compliant
• v4.6 expands to 64 wireless zones
(PC5204, PC5208)
• Template programming with RFK5564 keypad
• Connect up to 8 supervised keypads • Supports WT5500 wire free keypads

with keypad zones with TR5164-433 transceiver

Approval Listings: FCC/IC, UL/ULC, SIA CP-01, CSFM

PowerSeries panels, keypads & modules 3
