Page 47 - Hikvision - Ghid rapid- 2017-Q4
P. 47
24MP PROJECT SERIES
NEW
Model Name 24 MP PanoVu Camera
Model DS-2CD6A64F-IHS/NFC
Image Sensor 1/1.8″ Progressive Scan CMOS
(Panoramic)
Min. Illumination Color: 0.01 Lux @ (F1.2, AGC ON) B/W:
(Panoramic) 0.001Lux @ (F1.2, AGC ON)
Lens (Panoramic) 5.5 mm/F1.8
Field of View Horizontal field of view: 180° Vertical field of
(Panoramic) view: 80° Diagonal field of view: 196°
Video Compression Main stream: H.265/H.264 Sub stream:
(Panoramic) H.265/H.264
Image Sensor (PTZ) -
Min. Illumination (PTZ) -
IR (PTZ) -
Focal Length (PTZ) -
Horizontal FOV (PTZ) -
Pan and Tilt Range (PTZ) -
Patrol (PTZ) -
Video Compression (PTZ) -
Alarm Input/ Output 2/2
Audio Input/ Output 1/1
Support Micro SD/SDHC/SDXC card (128G),
local storage and NAS (NFS,SMB/CIFS), ANR
Power Supply 36 VDC ± 20%, terminal block
36 VDC ± 20%: max. 60W/1.6A
IP66
47
NEW
Model Name 24 MP PanoVu Camera
Model DS-2CD6A64F-IHS/NFC
Image Sensor 1/1.8″ Progressive Scan CMOS
(Panoramic)
Min. Illumination Color: 0.01 Lux @ (F1.2, AGC ON) B/W:
(Panoramic) 0.001Lux @ (F1.2, AGC ON)
Lens (Panoramic) 5.5 mm/F1.8
Field of View Horizontal field of view: 180° Vertical field of
(Panoramic) view: 80° Diagonal field of view: 196°
Video Compression Main stream: H.265/H.264 Sub stream:
(Panoramic) H.265/H.264
Image Sensor (PTZ) -
Min. Illumination (PTZ) -
IR (PTZ) -
Focal Length (PTZ) -
Horizontal FOV (PTZ) -
Pan and Tilt Range (PTZ) -
Patrol (PTZ) -
Video Compression (PTZ) -
Alarm Input/ Output 2/2
Audio Input/ Output 1/1
Support Micro SD/SDHC/SDXC card (128G),
local storage and NAS (NFS,SMB/CIFS), ANR
Power Supply 36 VDC ± 20%, terminal block
36 VDC ± 20%: max. 60W/1.6A
IP66
47
