UTION SERIES 8MP 16MP NEW NEW NEW
NEW NEW
Model Name PanoVu Series 180° Panoramic + PTZ PanoVu Series 180° Panoramic + PTZ PanoVu series 360°Panoramic PanoVu series 360°Panoramic+PTZ PanoVu Series 360° Panoramic + PTZ
Camera Camera
Camera Camera Camera
Model DS-2DP0818Z-D DS-2DP0818ZIX-D/236 DS-2DP1636-D DS-2DP1636Z-D DS-2DP1636ZIX-D/236
Image Sensor 1/1.9’’ Progressive Scan CMOS Four 1/1.8" Progressive Scan CMOS 1/1.9’’ Progressive Scan CMOS 1/1.9’’ Progressive Scan CMOS Eight 1/1.8" Progressive Scan CMOS
(Panoramic)
Min. Illumination Color: 0.005 Lux @ (F2.2, AGC ON), B/W: Color: 0.005 Lux@(F2.0, AGC ON), B/W: 0.0005 Color: 0.004Lux @ (F1.8, AGC ON), B/W: Color: 0.005 Lux @ (F2.2, AGC ON), B/W: Color: 0.005 Lux@(F2.0, AGC ON), B/W: 0.0005
(Panoramic) 0.0005Lux @ (F2.2, AGC ON) 0.0005Lux @ (F2.2, AGC ON) Lux@(F2.0, AGC ON)
Lux@(F2.0, AGC ON) 0.0004Lux @ (F1.8, AGC ON)
Lens (Panoramic) F5.0mm/ F2.2 F5.0mm/ F2.0 F4.0mm/ F1.8 F5.0mm/ F2.2 F5.0mm/ F2.0
Field of View Horizontal angle of view: 180°, Vertical angle Horizontal : 180°, Vertical: 80° Horizontal angle of view: 360°, Vertical angle Horizontal angle of view: 360°, Vertical angle Horizontal : 360°, Vertical: 80°
(Panoramic) of view: 80°
of view: 180° of view: 80°
Video Compression H.264(Baseline, Main, High Profile)/MJPEG Main Stream: H.265/ H.264 Sub-Stream: H.264(Baseline, Main, High Profile)/MJPEG H.264(Baseline, Main, High Profile)/MJPEG Main Stream: H.265/ H.264 Sub-Stream:
(Panoramic) H.265/ H.264/ MJPEG Third Stream: H.265/ H.265/ H.264/ MJPEG Third Stream: H.265/
H.264/ MJPEG H.264/ MJPEG
Image Sensor (PTZ) 1/1.9’’ Progressive Scan CMOS 1/1.8" Progressive Scan CMOS - 1/1.9’’ Progressive Scan CMOS 1/1.8" Progressive Scan CMOS
Min. Illumination (PTZ) Color: 0.002Lux @ (F1.5, AGC ON), B/W: Color: 0.002 Lux@(F1.5, AGC ON), B/W: 0.0002 - Color: 0.002Lux @ (F1.5, AGC ON), B/W: Color: 0.002 Lux@(F1.5, AGC ON), B/W: 0.0002
0.0002Lux @ (F1.5, AGC ON) Lux@(F1.5, AGC ON), 0 Lux with IR 0.0002Lux @ (F1.5, AGC ON) Lux@(F1.5, AGC ON), 0 Lux with IR
IR (PTZ) NA IR distance: 200m; IR brightness and angle - NA IR distance: 200m; IR brightness and angle
are adjustable. are adjustable.
Focal Length (PTZ) 5.7 – 205.2mm, 36X 5.6 to 208mm, 36× optical zoom - 5.7 – 205.2mm, 36X 5.6 to 208mm, 36× optical zoom
Horizontal FOV (PTZ) 58.7°- 2.0°(Wide-Tele) 62.5° to 1.9° (Wide-Tele) - 58.7°- 2.0°(Wide-Tele) 62.5° to 1.9° (Wide-Tele)
Pan and Tilt Range (PTZ) Pan: 360° endless; Tilt: -15°~ 90° (Auto flip) Pan: 360°, Tilt: -15° to 90° - Pan: 360° endless; Tilt: -15°~ 90° (Auto flip) Pan: 360°, Tilt: -15° to 90°
Patrol (PTZ) 8 patrols, up to 32 presets per patrol 8 patrols, up to 32 presets per patrol - 8 patrols, up to 32 presets per patrol 8 patrols, up to 32 presets per patrol
Video Compression (PTZ) H.264(Baseline, Main, High Main Stream: H.265/ H.264 Sub-Stream: - H.264(Baseline, Main, High Main Stream: H.265/H.264 Sub-Stream:
Profile)/MJPEG/MPEG4 H.265/ H.264/ MJPEG Third Stream: H.265/ Profile)/MJPEG/MPEG4 H.265/H.264/MJPEG Third Stream:
H.264/ MJPEG H.265/H.264/MJPEG
Alarm Input/ Output 7/2 7/2 7/2 7/2 7/2
Audio Input/ Output 1/1 1/1 1/1 1/1 1/1
Built-in Micro SD/SDHC /SDXC card slot, up to Built-in memory card slot, support Micro Built-in Micro SD/SDHC /SDXC card slot, up to Built-in Micro SD/SDHC /SDXC card slot, up to Built-in memory card slot, support Micro
128GB, manual/alarm recording SD/SDHC/SDXC (up to 128GB) 128GB, manual/alarm recording 128GB, manual/alarm recording SD/SDHC/SDXC (up to 128GB)
Power Supply 36 VDC 36 VDC 36 VDC 36 VDC 36 VDC
70W Max (Heater 22W) 105 W Max. 110WMax (Heater: 44W) 120 W Max (heater: 44W) 130 W Max.
IP66 standard, TVS 6,000V lightning IP66 Standard, TVS 6000V Lightning IP66 standard, TVS 6,000V lightning IP66 standard, TVS 6,000V lightning IP66 Standard, TVS 6000V Lightning
protection, surge protection and voltage Protection, Surge Protection and Voltage protection, surge protection and voltage protection, surge protection and voltage Protection, Surge Protection and Voltage
transient protection Transient Protection transient protection transient protection Transient Protection
46
