el Name DS-6700 HFI series Encoder DS-6700 HWI series Encoder DS-6700HQHI-SATA Series Encoder 67 SERIES ENCODER
Model
Video compression DS-6700HFI DS-6700HWI DS-6700HQHI-SATA
Analog video input H.264 / MPEG4 / MPEG2 / MJPEG H.264 / MPEG4 / MPEG2 / MJPEG H.264
Audio input 1-ch 1-ch 8-ch
Two-way audio in 1-ch, 3.5mm interface (2.0 Vp-p, 1 kΩ) (Line in) 1-ch, 3.5mm interface (2.0 Vp-p, 1 kΩ) (Line in) 4-ch, RCA (2.0 Vp-p, 1 KΩ)
1-ch, 3.5mm interface (2.0 Vp-p, 1 kΩ) 1-ch, 3.5mm interface (2.0 Vp-p, 1 kΩ) 1-ch, RCA (2.0 Vp-p, 1 KΩ)(using the 1st channel of
HDMI/VGA output audio input)
HDMI2 output
Encoding resolution 4CIF / 2CIF / CIF / QCIF 4CIF / 2CIF / CIF / QCIF 32 Kbps to 10 Mbps
Video bitrate 32 Kbps ~ 3072 Kbps, or user defined (Max. 8192 Mbps) 32 Kbps ~ 3072 Kbps, or user defined (Max. 8192 Mbps) 1-ch, RCA (Linear, 1 KΩ)
Audio output 1-ch, 3.5mm interface (Linear, 600 Ω) 1-ch, 3.5mm interface (Linear, 600 Ω) 64 Kbps
Audio bitrate 64 Kbps 64 Kbps 1 SATA interface
SATA 1 microSD, up to 32GB 1 microSD, up to 32GB Up to 6 TB capacity for each disk
Capacity 1, RJ45 10M/100M self-adaptive Ethernet interface
Network interface 1x 10M/100Mself-adaptive Ethernet interface 1x 10M/100Mself-adaptive Ethernet interface 1, RS-485; half-duplex
Serial interface 1 half-duplex RS-485 interface 1 half-duplex RS-485 interface 8/4
Alarm in/out 1/1 1/1 12 VDC
Power supply 12V DC adapter, or via PoE 12V DC adapter, or via PoE ≤ 30 W
Consumption(without ≤ 6 W ≤ 6 W
hard disks)
Working temperature -10 °C ~ +55 °C (14 °F ~ 131 °F) -10 °C ~ +55 °C (14 °F ~ 131 °F) -10 ºC to +55 ºC (14 ºF to 131 ºF)
Working humidity 10% ~ 90% 10% ~ 90% 10% to 90%
Chassis 380 mm 1U chassis
