FIXED TURRET CAMERA VARI-FOCAL TURRET CAMERA ECONOMIC SERIES

Model Name HD1080P WDR IR Turret Camera HD1080P WDR EXIR Turret Camera HD1080P WDR Vari-focal EXIR Turret
Camera
Model DS-2CE56D5T-IRM DS-2CE56D5T-IT3
Image Sensor 2MP CMOS Image Sensor 2MP CMOS Image Sensor DS-2CE56D5T-VFIT3
Effective Pixels 1944(H)*1092(V) 1944(H)*1092(V) 2MP CMOS Image Sensor
Min. illumination 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR; 0.014 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR; 0.014 1944(H)*1092(V)
Lux @ (F1.4,AGC ON),0 Lux with IR Lux @ (F1.4,AGC ON),0 Lux with IR 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR; 0.014
Lens 2.8mm 2.8mm Lux @ (F1.4,AGC ON),0 Lux with IR
Day & Night ICR ICR 2.8~12mm
Angle Adjustment Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360° ICR
WDR 120dB 120dB Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360°
Video Frame Rate 1080p@25fps/1080p@30fps 1080p@25fps/1080p@30fps 120dB
HD Video Output 1 Analog HD output 1 Analog HD output 1080p@25fps/1080p@30fps
CVBS Output 1Vp-p Composite Output(75Ω/BNC) 1 Analog HD output
Operating Conditions -30 °C – 60 °C (-22 °F – 140 °F), Humidity -30 °C – 60 °C (-22 °F – 140 °F), Humidity 1Vp-p Composite Output(75Ω/BNC)
90% or less (non-condensing) 90% or less (non-condensing) -30 °C – 60 °C (-22 °F – 140 °F), Humidity
Power Supply 12 VDC±15% 12 VDC±15% 90% or less (non-condensing)
Power Consumption Max. 4W Max. 5W 12 VDC±15%
Protection Level IP66 IP66 Max. 7W
IR Range Up to 20m Up to 40m IP66
Dimensions 89.6 × 59.1 mm (3.53” × 2.33”) Φ 114.6 × 89.1mm(Φ 4.5” × 3.5”) Up to 50m
Weight 340 g 450 g Φ 130.54 × 93.24 mm (Φ 5.14” × 3. 67”)
670 g
