Kantech Access Control and Security Management System
Intevo (Integration Evolution)
Technical Specifications:
Physical Mobile Device
Cabinet Dimensions Compatibility iPhone, iPod Touch,iPad and
(HxWxD) 5.4 x 30 x 29 cm Android (phone and tablet)
Cabinet Weight 3.7 kg Resolution CIF\2CIF\4CIF\1MP\720P\2MP\108
Environmental 0P\3MP\5MP\10MP
Operating Temperature 0° to 60° C indoor use only Compression (Recording) H.264, MPEG-4, MJPEG
Humidity Maximum 93% relative Recommended System Capacities
humidity non-condensing Recommended maximum capacities for the Intevo server:
Electrical Card Readers 256
Input 100-240 VAC, 50-50 Hz, 2.0 A Card Users 10,000
Output 12 VDC, 80 W maximum Card User Access Levels
Power Consumption 60 W 250 (per site)
General Features Access Level
Processor Intel Core i3-2330E Combinations Unlimited
Processor Schedules 100 (per site)
Memory 4GB, Non-ECC, 800MHz Holidays 366
DDR3 SODIMM System Operator
Video Card Integrated Intel GMA HD Passwords Unlimited
Graphics Operator Security Levels Unlimited (pre-defined)
Hard Drive 1 32GB SSD Boot Drive Concurrent System
Hard Drive 2 3TB 3.5in Audio-Video SATA Languages 2
(3Gb/s) Multi-Site Gateways 1
Drive (24/7 DVR Grade) Serial /USB Sites 32
Remote IP Sites 64
Operating System Windows Embedded Concurrent EntraPass
Standard 7 Webstation Logins 4 (1 included with Intevo)
Network Dual gigabit Ethernet Concurrent EntraPass
10/100/1000 Base-T, RJ45 Workstation Logins
USB 6 USB 2.0 connectivity ports, (with live video capability) 10 (2 +1 included with
two front/four rear Intevo)
Serial Port 1 RS-232 serial port IP Cameras 32
eSATA Dual eSATA storage For more information on supported IP video devices, visit:
www.americandynamics.net/Products/Hybrid_Digital_Video_
expansion port
Recorders.aspx
Display Dual high definition display
outputs (VGA, DVI and HDMI)
Video streaming Integration Capabilities
Intrusion
Throughput 128 Mbps (Input 50 Mbps) DSC Alarm Panels (PC1616, PC1832, PC1864,
PC4020), Bentel Alarm Panels KYO 320
Fans Temperature controlled Honeywell Dimension by adding the software module
E/CORE/GLY and providing the Honeywell Ethernet
Software EntraPass Corporate Edition module Video American Dynamics HDVR.
and American Dynamics
HDVR (IP cameras only)
Monitoring Watchdog timer, CPU
voltage monitoring,
CPU temperature monitoring, VideoEdge
NVR, TVR Series, Intellex Digital Video Management
Smart Fan control, System Systems and more.
power management
Warranty 3-year warranty
01/14 24
